High configuration 5-ton hydraulic uncoiler Equipment parameters: 1. Equipment size: 3200 * 1500 * 1800mm 2. Equipment frame: The base is made of 300H steel, and the front plate of the box is welded with 16mm thick steel plate 3. Equipment spindle: support material spindle: made of thick walled seamless steel pipe, with a diameter of 194 * 40mm 4. Hydraulic cylinder: One expansion cylinder with a diameter of 125mm * 100 (with a rotary joint) 5. Hydraulic pump station: 3kw (pump valve Beijing Huade) 6. Rated power of the host: 3kw Shanghai Bojiang brand 7. Inner diameter of steel coil: 470-520mm 8. Feeding width: 1250mm 9. Equipment bearing capacity: 5 tons, equipment weight is about 2.8 tons (including trolley) 10. Electrical control system: 5.5kw frequency converter, Sanjing brand, and Delixi electrical control components 11. Attachment: With auxiliary support, wall pressing device, and feeding trolley Advantages: 1. The load-bearing spindle is made of high-strength, fatigue resistant seamless steel on the rear wall, which has been turned and processed, with strong strength and high load-bearing capacity. 2. The expansion coil adopts hydraulic control, which is convenient, fast, and stable. 3. Electrical control, high precision, good automation, frequency converter control, and adjustable speed
Tile pressing machinery Equipment installation overall size: 8000mm × 1500mm × 1800mm Feed width: 1250mm. The feeding platform adopts a manual adjustment for precise feeding Feed plate thickness: 0.4~1.0mm galvanized sheet, color steel plate Forming shaft diameter: 80mm diameter (solid spindle) Forming process: 15 rows+15 rows forming Roller material: Large roller 45 # precision turning, deep quenching, hard chromium plating, mirror plating (delayed for 1 hour), equipment weight approximately 8.5-9 tons (subject to actual equipment) Cutting method: reinforced hydraulic automatic floor cutting system (without material connection and labor saving) Hydraulic station power: 11kw high-speed hydraulic air-cooled belt heat dissipation pump station Drive mode: 7.5kw servo motor with fast speed and precise board output Main bearing: National standard quenched bearing steel bearing Equipment rack: thickened 400 # national standard H steel welding plate: 18mm Transmission method: 1.2 inch brand national standard quenching chain transmission Cutting blade material: Gr12 molybdenum vanadium blade, thick steel plate, welded, profiled, shear guide pillars, all thickened, reinforced, precision turned, quenched, shear oil cylinder, high-speed hydraulic oil cylinder Fixing method: Grade 8.8 high-strength screw, thickened wall tie rod, thickened square steel hanging wire plate Servo board output speed: single board 16-25 meters/minute, glazed tile 4-6 meters/minute Electronic control system: The entire machine adopts the most advanced electronic control system, with a 10 inch touch screen and a split electronic box of electronic components from brands such as Delixi Zhengtai. It can input 50 order sizes and has a broken board reminder function. Random accessories: one pair of upper and lower cutting knives, one solenoid valve, two counter wheels, four solenoid valve light caps, four travel switches, four buttons, and ten electronic fuses
