Hurricane Single Flame System can fire a desired (color) flame up to 10 meter high
in optimal conditions. The system consists of a small flame head and a fluid tank.
Inside the flame head, a small butane canister provides the gas for the pilot flame.
Once the safety system detects the pilot flame, it’s possible to generate a big (color) flame column.
8 or 11 or 16 liter capacity pressure tanks are the (color) flame fluid reservoir that
will be pressurized by an external nitrogen gas cylinder to get the required pressure for the system.
The height of the flame depends on the nozzle and working pressure of the system.
1.5 mm nozzle at 15 bar generates a flame of 5 - 6 meter high and 2 mm nozzle at 20 bar
generates a flame of 8 - 10 meter high.
Especificaciones
Características técnicasPOWER : 110V / 230V / 130W
DIMENSIONS : 37(L) x 35(W) x 53(H)
WEIGHT : 20kg
FLAME HEIGHT : 5 to 10m
MAIN FUEL : COLOR FLAME FLUID, Isopar G or H
